aNexus Xenon RS-4000 Water Sterilization System

GENERAL DESCRIPTION

Model RS-4000 uses pulsed UV light sterilization technology pioneered by the XENON Corporation. A revolutionary pulsed UV lamp at the heart of the system fires pulses of light that are 50,000 times brighter than sunlight and are powerful enough to kill high levels of all microorganisms and significantly reduce TOC.

FEATURES

• 100% kill of microorganisms -Unique xenon pulsed UV flashlamp delivers unprecedented levels of concentrated UVenergy.

• Short pulses prevent excessive heat build up and achieve rapid sterilization.

• Pulsed characteristics of high peak power deliver superior penetration for the destruction of microorganisms at deeper levels.

• No toxic materials such as mercury or microwaves are involved

• Fluid flow is contained in 316L Electro-polished Stainless Steel

• Electronics and controls are isolated from fluid.

• Model RS-4000 is designed and manufactured by XENON Corporation. Put our high performance, pulsed UV flash lamp manufacturing expertise to your use.

SPECIFICATIONS

Output

Pulse Width                     360 usee

Pulse Rate                        3 pulses/sec

Radiant Energy               1.27 joules/ern”

Electrical Energy             505 joules/pulse

                                          1,516 joules/sec

Input

Control Architecture:     Operator or PLC interface

Cooling Air (flashlamp): 100 CFM of dry filtered air

Utilities

Single phase Voltage:     200 -240 Vrms , 50/60 Hz

Maximum Line Power:   2500W

Maximum Line Current: 20 A @ 50 Hz, 18A @ 60 Hz

Compressed Air:              None required
